Technical specifications
RF
range - 70 ... 72 MHz
IF range - 28 ... 30 MHz
IF input power - 1 ... 50 mW
(0.05 W max.) or 0 ... 17 dBm
LO frequency - 42 MHz (42.000
MHz Fundamental crystal)
LO frequency stability - +/- 3
ppm
Output power - 10 ... 15 W
RX gain - typ. 20 dB
Noise figure - typ. 1.0 dB
Image rejection - typ. 70
dB
PTT control - Contact
closure to ground
Supply voltage - +13.8 V DC
(+12 ... 14 V DC)
Current consumption - typ. 2 A
(TX)
TX Output transistor - RD16HHF1
RX Input transistor - BF998
Dimensions (mm) - 80 x 45
